NE150 consists of rotating platform, walking device, working device, power, hydraulic pressure, electric control, braking and other systems. The motor is used to match the lithium battery, which is energy-saving and environmentally friendly, and the power system is optimized to meet the requirements of efficient operation


Operating Weight
13,900 KG
Bucket Capacity
0.5~0.7 m3
Max. Travel Speed
5.3 km/h
Dimension (LxWxH)
7750 x 2500 x 2760 mm
Max. Digging Reach
8197 mm
Max. Digging Depth
6039 mm
Max. Digging Height
8651 mm
Motor Rated Power
92 kW @ 2,000 rpm
Battery Type
Lithium Battery
Battery Capacity
210 kWh
Battery Voltage
